Memmert VO500

• Temperature range: 5°C above ambient to +200°C
• Display resolution (actual values):
 – 0.1°C up to 99.9°C
 – 0.5°C from 100°C and above
• Display resolution (setpoint values):
 – 0.1°C up to 99.9°C
 – 0.5°C from 100°C and above
• Setting accuracy:
 – 0.5°C up to 99.9°C
 – 1°C from 100°C and above

Vacuum System:
• Digital electronic pressure control via solenoid valves
• Vacuum adjustment range: 5 mbar to 1100 mbar (digital LED display)
• Setting accuracy: 1 mbar
• Rapid air intake for door release (door interlocked under vacuum)
• Process resumes automatically after power failure
• One programmable, digitally controlled air inlet

Controller Features:
• Digital display of all set parameters (temperature, pressure, time, weekdays, program status, and setup values)
• Separate LED symbol for each thermoshelf in operation
• Individual digital temperature display for each thermoshelf
• Auto-diagnostic function

Timer Functions:
• 7-day real-time program timer with minute precision
• Up to 40 programmable ramps for temperature, pressure, and time — each segment adjustable from 1 min to 99 hrs

Physical Specifications:
• Internal volume: 101 liters (3.56 cu ft)
• Interior dimensions: 545 × 465 × 400 mm
• Maximum chamber load: 60 kg
• External dimensions: 710 × 760 × 550 mm
• Weight: 110 kg
