Microstep DS 6001.20P CNC CONTROL
Ref :
2738545-3-CP
Condition :
Used
Manufacturer :
Microstep
Model :
DS 6001.20P
Controller :
CNC CONTROL
Year(s) :
-
Quantity :
1
Location :
Seller or machines location:
EUROPE (Western and Northern)
EUROPE (Western and Northern)
3D plasma bevel head cutting vertically and at an angle up to ±50° (auto calibration)
Hypertherm XPR 300 (piercing 45 mm / 6 mm straight cuts at 170 amp up to 200 mm/min)
Maximum sheet size: 6000 x 2000 mm
Material thickness: 3 > 30 mm
Plasma marking
Laser light
MG-40 P26 drilling device ISO 40
Drilling range: diameter 4 > 40 mm
Thread cutting: M4 > M33
Maximum thickness: 100 mm
Stroke: 400 mm
Spindle power: 26 kW
Maximum spindle speed: 1829 rpm
Automatic toolchanger with 8 tool positions
External tool cooling
Internal tool cooling
CNC control iMSNC system for Windows 10 64-bit PRO with integrated network card and USB port
Vacuum suction system for automatic sheet loading
Total weight: 30 t
Required space: 16500 x 7100 mm
