Mikron HPM 800U 5 Axis

MIKRON HPM 800U
2016

5 axis
A axis +91 ~ -121 degrees
C axis 0.001 degrees (360° full rotation)
Control Heidenhain iTNC530
Coolant system
Interlocked guards
Low voltage light
Multi pallet machine
Remote hand wheel
Swarf conveyor
Through spindle coolant
Tool setter
Twin pallet system
Number of pallets 2
Pallet size 500 x 500 mm
Pallet change time 30 seconds
Spindle speed 20,000 rpm
Spindle motor power 32 kW
Tool change capacity 60 stations
Tool size HSK A63
Maximum tool diameter 60 mm
Maximum tool diameter with empty adjacent pockets 160 mm
Maximum tool length 350 mm
Maximum workpiece height 500 mm
Maximum swing circle 800 mm
Maximum workpiece weight 800 kg
Rapid feedrates 45 m/min
Traverses X 800 mm
Traverses Y 800 mm
Traverses Z 550 mm
Dimensions 6300 x 4500 x 3475 mm
Weight 15,500 kg
