Mikron HPM 800U 5 Axis

MIKRON HPM 800U
2016

Traverse X axis 800 mm
Traverse Y axis 800 mm
Traverse Z axis 550 mm
A axis +91 ~ -121 degrees
C axis 0.001 degrees (360° full rotation)

Control Heidenhain iTNC530
Machine dimensions 6300 x 4500 x 3475 mm
Machine weight 15500 kg
Maximum tool diameter 80 mm
Maximum tool diameter with empty adjacent pockets 160 mm
Maximum tool length 350 mm
Maximum workpiece height 500 mm
Maximum swing circle 800 mm
Maximum workpiece weight 500 kg

Number of pallets 2
Pallet change time 30 seconds
Pallet size 500 x 500 mm
Rapid feedrates 45 m/min
Spindle motor power 36 kW
Spindle speed 20000 rpm

Through spindle coolant pressure 80 bar
Tool change capacity 60 stations
Tool size HSK A63

Coolant system
DXF conversion
Interlocked guards
Low voltage light
Remote hand wheel
Spindle probe
Swarf conveyor
Through spindle coolant
Tool setter
Twin pallet system
