Modern 0606CFT Lab Size Inline Style Thermoformer

Max Tool Size 6" x 6"
Max Draw Depth 4" (Above & Below Sheeline)
Sheet Width (Max & Min) 8" & 4"
Unwind Stand Free Standing (18" Dia Roll x 3" Cores)
Indexing Servo Indexing (Digitally Controlled)
Sheet Conveying #40 Pin Chain - 1" Centers on Points (Sprocketless Design)
Oven (Panel IR Heaters - Top Only) 30" Long / 5-Stop
Oven Elements Solar "F" Series Panel
Number of Zones (5) Zone
Oven Contol System Hetronik PID Oven Control System (Elec. Photo Sag Eye)
Bottom Mounted IR Sensor Monitors Sheet Temperature
Platens (4) Post Guiding
Platen Drives Servo Toggle Design (80 PSI) w/ Digital Encoder (For Positioning)
Top - Open/Closed (Daylight)/Stroke 7" / 3" / 4"
Bottom - Open/Closed (Daylight)/Stroke 7" / 3" / 4"
Trim Station (4) Post Trim Station (Servo w/ Encoders)
Trim Station Tonnage 10 Ton
Max Tool Weight 100 Lbs (Top & Bottom)
Index Length 6"
Trim Tool Stroke Dimensions Refer to Platen Top & Bottom Daylights Details
Control Allen Bradley Controller

Features
A Motorized Scrap Winder
Semi-Auto Tool Loading Mechanism
Vacuum Pump & Tank Reservoir
