Monguzzi AFD-35/2600

Veneer cutting guillotine
For clean, perfectly parallel and rectangular joining of veneer bundles in one operation.
Thanks to its high productivity, its careful handling of the raw material (no manual turning over) and its exactly parallel cut,
this guillotine is the perfect machine for preparing the veneer strips for splicing.

Production:
Up to 3 bundles/min.

Technical data:
Max. cutting length: 2600 mm
Cutting widths: 45 - 350 mm
Pressure beam opening: 100 mm
Pressure beam width: 350 mm
Parallel fence with digital read-out: 25 - 1000 mm
Cutting angle approx.: 45°

Features :
- Solid, heavy duty built with generously-dimensioned pressure beam and cutting table to absorb the high clamping and shearing forces
- Unique system with fixed, solid cutting table and movable pressure beam
- Laser lights for exact visual identification of cutting lines
- Quality hydraulic system with large oil tank
- Electric-motor-driven parallel stop with rapid adjustment
- Industrial computer based on Windows operating system, wide screen and keyboard
- Various modes of operation and storable program operations
- Extensive collection of production data
- Central lubrification unit

Movable Laser Lines
For optimizing veneer yield.
The manually operated laser line for the position of the front blade is quickly set.
The veneer width is transferred to the computer at the push of a button.
The cutting process then starts automatically.
