Mori Seiki DURAVERTICAL 5100 -618 3 Axis

X-axis travel: 1050 mm
Y-axis travel: 530 mm
Z-axis travel: 510 mm
Control: MSX-504 IV Mori Seiki
Spindle speed: max. 10,000 rpm
Spindle power: 15 / 11 kW
Tool taper: SK 40
Spindle bearing diameter: 70 mm
Distance spindle to table: 150 - 660 mm
Table size: 1350 x 600 mm
Max. table load: 1000 kg
T-slots: 6x 18 mm
Tool positions: 30
Max. tool diameter: 80 mm
Max. tool diameter with empty adjacent slot: 125 mm
Max. tool length: 300 mm
Max. tool weight: 8.0 kg
Tool change time (tool to tool): 1.3 sec
Tool change time (chip to chip): 4.1 - 9.2 sec
Rapid traverse (X/Y/Z): 36 / 36 / 20 m/min
Feedrate: 1 - 5000 mm/min
Tipp feedrate: 0 - 5000 mm/min
Total power requirement: 27 kVA
Machine weight: 6.4 t
Machine dimensions: 3.5 x 3.0 x 2.8 m
Includes chip conveyor
Includes coolant system
Includes various tooling
Includes documents
Includes high pressure coolant
Includes hydraulic system
Includes spindle oil cooler
