Mori Seiki NHX 4000 3rd Generation 4 Axis

MORI SEIKI NHX 4000 3rd Generation

X-travel: 560 mm
Y-travel: 560 mm
Z-travel: 660 mm
B-axis: Fully integrated 360.000 x 0,001°

Control: Celos Siemens 840D SL Operate ERGOline Multitouch
Turning speeds: 20 – 15.000 1/min
Spindle drive: 46 / 30 kW
Max. torque on the spindle: 200
Tool taper: HSK-A63
Number of tool station: 123

Diameter of tools max.: 70 mm
Tool diameter with no neighbouring tools: 170 mm
Tool length max.: 450 mm
Weight of tools max.: 12 kg
Numbers of pallets: 2
Pallet dimension: 400 x 400 mm

Max. workpiece diameter: 630 mm
Workpiece height max.: 900 mm
Table load: 400 kg

Rapid travel x/y/z: 60 m/min
Feed x/y/z: 60 m/min

Chip conveyor
Internal coolant system feed: 40 bar / 23 l/min

Total power requirement: kVA
Weight of the machine ca.: 8,5 t
Dimensions: 3200 x 4800 x 2900 mm

Additional Equipment:
Rotoclear window
Signal lamp 4 colours
Electronic handwheel
Probe for tool breakage and length measuring
Coolant shower
Renishaw probe (spindle)
HSK cone cleaning station with brushes
