Mori Seiki NHX 4000 3rd Generation 4 Axis

X travel: 560 mm
Y travel: 560 mm
Z travel: 660 mm
Rapid traverse X/Y/Z: 60 m/min
Feed rate X/Y/Z: 60 m/min
B-axis: 360° x 0.001°
Control: Celos Siemens 840D SL Operate ERGOline Multitouch
Chip conveyor
Internal coolant system
Coolant through spindle: 40 bar
Internal coolant supply: 70 bar
Electronic handwheel
Tool breakage and length measuring probe
Coolant shower
Renishaw spindle probe
HSK cone cleaning station with brushes
Rotoclear window
Signal lamp 4 colors
Max. workpiece diameter: 630 mm
Max. workpiece height: 900 mm
Table load: 400 kg
Spindle speed: 20 – 20,000 rpm
Spindle drive power: 25 / 35 kW
Max. spindle torque: 86 / 130 Nm
Tool taper: HSK-A63
Number of tool stations: 60
Max. tool diameter: 70 mm
Max. tool diameter without adjacent tools: 170 mm
Max. tool length: 450 mm
Max. tool weight: 12 kg
Number of pallets: 2
Pallet size: 400 x 400 mm
Machine weight: approx. 8.5 t
Machine dimensions: 3200 x 4800 x 2900 mm
