MULLER MARTINI Amigo Saddle Stitcher

Binding Type EVA Hot Melt Perfect Binder
Book Clamp Configuration 4 clamps
Maximum Mechanical Speed Up to 1,500 cycles/hour
Book Block Feed Manual hand feed
Cover Feed Automatic pile cover feeder
Spine Preparation Milling and roughening station
Dust Removal Integrated dust extraction
Glue Application Spine glue with side gluing
Nipping Station Hydraulic/mechanical nipping and pressing
Cover Scoring Dual scoring wheels, adjustable
Book Delivery Automatic conveyor delivery
Maximum Book Size Approximately 12.6" × 12.6" (320 × 320 mm)
Minimum Book Size Approximately 4.7" × 4.7" (120 × 120 mm)
Maximum Book Thickness 2.0" (50 mm)
Minimum Book Thickness Approximately 0.08" (2 mm)

Standard Features:
Four-book clamp transport system
Manual block feeding
Automatic cover feeder
Milling and notching station
Spine roughening
EVA hot-melt glue pot
Side gluing discs
Adjustable cover scoring
Nipping station
Automatic delivery conveyor
Central operator control panel
Variable speed drive
Integrated glue temperature controls

Electrical Requirements:
Voltage: Typically 208–240 VAC, 3 Phase (varies by market)
Frequency: 50/60 Hz
Compressed Air: Approximately 6 bar (87 psi)
