Multipack, OMET TV503 / TA 501 F/ NK Millennium 50
EUROPE (Western and Northern)
Condition Used
OMET TV 503 Napkins Making Machine (Year 2005)
Products: Napkins of tissue or Non-woven | Model No. : TV 503 C 5A 2G IR TA
Minimum size: Unfold Napkins Standard 250 x 250 mm
Maximum size: Unfold Napkins: 480 mm X 480 mm
Maximum Roll Width: 500 mm
Maximum Roll Diameter: 1800 mm
Maximum Roll Weight: 380 kg
Core Diameter Standard: 76.2 mm (3")
Printing unit: Yes
Air Pressure Required 6 bar
Mechanical speed: Max. 550 m/min
Productivity: Depend on the size/type of folding/quality of paper/condition of paper roll / embossing/printing/capacity of dryer and nr. of colors printing
Documents Available: Complete Operation Manual with Safety Standard, Installation,
Cycle Description, Controls and Settings, Size Changing, Maintenance, Trouble-Shooting and Equipment Diagrams
Output material packing is done manually
Machine can produce: 1 or 2 layer napkins. With embosser can be made 3 layer napkins
The width of napkins can be: 24, 33 or 40.cm
OMET - TA 501 F Transfer Unit (Year 2005)
Machine Use: Transfer Unit for collect, Count and deliver to the wrapper the napkins produced on the folder | Model No. : Tta 501 F
Minimum size: Unfold Napkins Standard 250 x 250 mm
Maximum size: Unfold Napkins 480 mm X 420 mm
Maximum Pack Height: 190 mm
Minimum Pack Height: 20 mm
Mechanical speed: Max. 550 Cycles/min
Air Pressure Required: 6 bar
Documents Available: Complete Operation Manual with Safety Standard, Installation, Cycle Description,
Controls and Settings, Size Changing, Maintenance, Trouble-Shooting and Equipment Diagrams
MULTIPACK NK Millennium 50 (Year 2006)
Machine Type: Napkin Automatic Packaging Machine
Machines composed by: product infeed/bundling section/side sealing module & vaccuum pump |Model No. NK Millennium 50
Electrical parameter 400V - 50HZ + T + N
Air Pressure Required 6 bar
Input Power 9 KW
Documents Available: Complete Instruction Manual with machine description, Functional Display,
Display Massages details, Starting/ End of production, Machine cycles, home knife positioning
