Multivac R 140, Thermoforming machine 420 mm
Ref :
2497170-5-MT
Condition :
Used
Manufacturer :
Multivac
Model :
R 140, Thermoforming machine
Product Size :
420 mm
Year(s) :
2007
Quantity :
1
Location :
Seller or machines location:
RUSSIA and Central Asia
RUSSIA and Central Asia
Film width: 420 mm
Upper film width: 405 mm
Designed for packing products in vacuum packages.
Suitable for all kind of products:
fish, meat, poultry, vegetables, IQF products.
All products in packages made by Multivac will be fresher
for a long time and will be protected from unwanted particles
entering the product. Work on the semi-rigid film
with thickness 90 microns for upper film
and 200 microns for a lower film. Depth 45 mm.
Power: 9 kW
Voltage: 3 x 400 V \ 50 Hz
Die set:
1. 2:1 outside dimensions 401 x 150 mm, inside dimensions 386 x 150 mm
2. 3:1 outside dimensions 300 x 133 mm, inside dimensions 282 x 118 mm
3. 2:2 outside dimensions 205 x 150 mm, inside dimensions 185 x 132 mm
