Murakami Hide CLEAN TANKER 4990DWT

Murakami Hide shipbuilding Japan
4990DWT CLEAN TANKER
(Double Bottom / Single Hull)
BLT Jun 1996

Type of Vessel:Clean Tanker(Fire-Proof Construction Vessel) :
Flag :Japan
Class :N.K. / Coastal

LXBXD:101.15m*14.60m*7.70m/6.75m
G/T :2,996
DWT :4,999

C.O.T. Capacity :No.1~ No.4 C.O.T. (P/S), Total 5, 599.631 m3
C.O.T. Coating :Fully Epoxy coated
Pumps - Cargo Pump : Taiko, Screw type, 1,500 m3/h x 8.5
Heating Coil :NIL

M/E :Akasaka, DM47M 4,000 PS (2,941 Kw) x 260 rpm
Consumption:At Ballasting: 410 Ltrs/h x 245 rpm on 13.5 Knots
At Full Load: 490 Ltrs/h x 250 rpm on 12.5 Knots
A/E :Yanmar, 540 PS x 720 rpm x 2 sets, S185DL-ET,
Consumption: 60~ 65 Ltrs/h x 1 set
: Yanmar, 200 PS x 1,200 rpm x 1 set, 6HAL-DTN,
Generator :450 KVA x 720 rpm x 445 V x 2 sets
:175 KVA x 1,200 rpm x 445 V x 1 set
Speed :14 Knots (Full Speed)
Shaft Generator : Nil
Boiler (Thermo Heater) : Takuma, 8.5 Kg/cm2
Bow Thruster : Kawasaki, Electric Controllable Pitch, Propulsion: 5 tons


PRESENT CARGO:et Oil & Clean Oil

SPARES : FYI, the following items are now on board as spares.
- M/E Cylinder Cover x 1 pc, Piston x 1, Connecting Rod x 1,
Liner x 1, Fuel Oil Injection Pump x 1,
- Starting Valve x 6, Exhaust Valve x 6, Inlet Valve x 6
Complement :Total 12 persons (5 Officers + 7 Crew)

Survey Status:28th/Apr/2008: Passed Annual Survey
28th/Apr/2010: Passed Special Survey
24th/Jun/2015: Next Special Survey Due
