Niigata HN-800V 4 Axis

X axis travel 60.2" (1529 mm)
Y axis travel 48.4" (1229 mm)
Z axis travel 48" (1219 mm)
CNC control FANUC 30iB
3 axis
Pallet size 31.5" x 31.5" (800 x 800 mm)
Maximum workpiece swing diameter 68.9" (1750 mm)
Maximum pallet load 5500 lbs (2494.76 kg)
Spindle speed 8000 RPM
Spindle motor 73 HP (55 kW)
Spindle taper CAT 50 Big Plus
Spindle torque 886 ft-lbs (1202 Nm)
Rapid traverse X axis 2361 IPM (60 m/min)
Rapid traverse Y axis 2361 IPM (60 m/min)
Rapid traverse Z axis 2361 IPM (60 m/min)
Automatic tool changer 90 tools
ATC type chain
Tool to tool time 2.5 sec
Table indexing 1° (0.001°)
Machine weight 68500 lbs
Hybrid guideway system
Roller guideways on X and Z axes
Box guideway on Y axis
One-piece T-shape base
Honeycomb structure base
3 point leveling system
