Used Looms (rapier)
475 resultsStaubli dobby with 16 shafts AT1 panel Each loom equipped with: 10 frames 4 ECS and 2 accumulators 2 cloth ro Year(s) : 1996 Location : MIDDLE EAST
Price : On request
More details2 looms Thema 11 Excel year 1995 and 1998 Staubli dobby 2660 with 20 shafts (all installed) 1 loom Super Exce Year(s) : 1995, 1998, 2001 Location : EUROPE (Central and Eastern)
Price : On request
More details38 x Picanol Gammax – 8- R of year 2006 width 190cm Staubli dobby 2861 with 20 shafts installed 6 looms with u Year(s) : 2003, 2006 Location : EUROPE (Central and Eastern)
Price : On request
More detailsYEAR 2x2005 and 2x2003 4 COLORS SELECTOR WITH SUMO MOTOR FREE FLIGHT PREDISPOSED FOR BEAMS FLANGE 1000 mm STAU Year(s) : 2003, 2005 Location : EUROPE (Western and Northern)
Price : On request
More detailsFOUR MACHINES ARE IN PERFECT WORKING CONDITION PACKAGED AND READY TO SHIP Location : Russia
International Socks Ltd
Jun, 30
8 Color Weft selectors GC Guided Rapiers Staubli Electronic Dobby Year(s) : 2020 Location : MIDDLE EAST
Price : On request
More details1 set with STAUBLI DOBBY & 1 set with cam motion Weaving from creel (without creel) with dummy outside the loo Year(s) : 1990 Location : ASIA (South)
Price : On request
More detailsElectronics Take Up Motion Electronic Let-off Motion : 1.5 Warp beam 1.5 Number of Cloth Roller Year(s) : 1998, 1999 Location : ASIA (South)
Price : On request
More detailsStaubli dobby 20 shafts 12 frame installed 2 accumulators working condition Year(s) : 2014 Location : MIDDLE EAST
Price : On request
More detailsSulzer P7100 2 colours Cam box with 10 shafts Serial numbers: from 10955-114033 Electrical let off Each loom Year(s) : 1990 Location : MIDDLE EAST
Price : On request
More detailsStaubli dobby with 20 shafts (16 installed) Each loom equipped with: 4 colours 3 accumulators 1,5 beams 1,5 c Year(s) : 1996 Location : MIDDLE EAST
Price : On request
More details16 levers 8 color 4 feeder 8 frame 1 beam 1 roller 1 reed running condition Year(s) : 2016 Location : ASIA (China - Taiwan - HKG)
Price : On request
More detailsItaly original 6 sets width 340cm 12 sets width 380cm 500+ rpm 4 feeder 12 frame 1 beam 1 roller good conditio Year(s) : 2014 Location : ASIA (China - Taiwan - HKG)
Price : On request
More detailsStaubli Dobby 2670 (16/20 shafts) Accessories: 6 Heald Frames 2 LGL Pre-winders 1.5 Beams(800mm/1000mm) 1.5 Year(s) : 1998 Location : ASIA (South)
Price : On request
More details3 feeder 6 frame 12 shafts 1 beam, 1 roller RPM 556-630 running conditions Year(s) : 2016 Location : ASIA (China - Taiwan - HKG)
Price : On request
More details2 feeder, 8 frame, 20 shafts 1 roller, 1 beam 27 x 230cm width (include 23 sets Super excel & 4 sets Excel) 25 Year(s) : 2002 Location : ASIA (China - Taiwan - HKG)
Price : On request
More detailsStaubli dobby 2670 with 16 levers installed 8 colors Each loom equipped with: 6 ECS 3 accumulators Luna X2 8 Year(s) : 2008 Location : EUROPE (Western and Northern)
Price : On request
More detailsItaly brand Staubli 2668 2 feeder,4/6 frames 1 beam 1 roller can test running Year(s) : 2000 Location : ASIA (China - Taiwan - HKG)
Price : On request
More detailsfimtextile dobby 6 frame, 2 feeder 1.5 beam, 2 roller running conditions Year(s) : 2008 Location : ASIA (China - Taiwan - HKG)
Price : On request
More detailsLooms can be sold individually 1 Sulzer G6300 width 360cm year 2000 Staubli dobby 2622 with 12 shafts capacit Year(s) : 2000, 2003 Location : EUROPE (Western and Northern)
Price : On request
More detailsSTAUBLI DOBBY 2667 20 SHAFTS INSTALLED 7(1)-5(1) ECS COLOUR SELECTOR AT1 DIALOG PANEL 1 BEAM 1 CLOTH ROLLER 10 Year(s) : 1993 Location : EUROPE (Western and Northern)
Price : On request
More detailsff type with staubli dobby 20 shaft -(all installed) For each looms; -4 accumulators -1,5 beam -1,5 cloth ro Year(s) : 2020 Location : MIDDLE EAST
Price : On request
More detailsSUMO Motor Staubli 2861 Dobby 20 Shafts Guide Hook System Each loom with 1.5 beams 1.5 cloth roller 10 heald Year(s) : 2001, 2005 Location : ASIA (South)
Price : On request
More details12 x P1001 ES working width 190cm yoc 1996-1998 with Fimtextile dobby RD80040 3 x P1001 Super EK working widt Year(s) : 1996, 1997, 1998, 2000 Location : EUROPE (Western and Northern)
Price : On request
More detailsStaubli dobby 20 shafts AT1 panel WLO / ETU Colour selection system modified with cable selectors but machine Year(s) : 1996 Location : EUROPE (Western and Northern)
Price : On request
More detailsYear(s) : 2001 Location : -
Price : On request
More detailsYou can find used Looms (rapier) on Wotol
Rapier weaving is one of the technology for weaving with, air jet weaving, water jet weaving, projectile weaving.
There are still few weaving companies using older methods like shuttle looms weaving and even hand weaving.
With rapier looms the weft yarn is carried through the warp with rapiers.
In rapier technology the weft yarn is carried by grippers with flexible tapes or rigid profiles.
The grippers meet in the meedle of the loom and exchange the yard.
There are two types of grippers: negative grippers which is the most common type and positive grippers.
Positive gripper offers the best flexibility because it can catch any type of yarn during the same weaving process.
Rapier weaving is the most commonly used technology. It offers more versality than other technoligy such as air jet and higher productivity than projectile looms as an example.
Rapier weaving is suitable for any type of fabric: clothing, home fursnishing or technical.
The width of the looms varies from 150cm to 540 cm for the widest.
They can be fitted with dobby (also cam) and jacquard.
Main air jet looms producers are Picanol (Belgium), Dornier (germany), Itema (Italy), Sulzer (Swiss), Somet (Italy), Vamatex (Italy), SMIT (Italy), Panter (Italy) and older manufacturers like Nuovo Pignone (Italy) Saurer Diedrich (France) of SACM MAV (France).
Q&A corner - questions and answers received from members
Q: Is Dornier the only loom with positive grippers?
A: There are other looms with positive grippers such as Panter or the Saurer Vamatex 9000+ but Dornier is the most spread and popular brand. Picanol is working on positive grippers too.
Q: What is the benefit of Picanol Sumo motor?
A: Picanol Sumo motor gives you more flexibility. It can manage the slow motion. Also it is more eco friendly because it has lower electric consuption. It also enalbles an easy pick finding.
Q: I have been offered recent G6300 but I thought Sulzer stopped production in before 2004.
A: Seems the G6300 is now produced in China under license by an other brand but we don't have many information about it.
Q: What is the difference between free flight and guided hooks?
A: In guided hook rapier technology the tape that holds the gripper is driven inside a chanel of hooks. IN the case of free flight there is no more hooks. There is less friction with the free flight technology but for some types of fabric this technology is not suitable and guided hood is recommended.
Q: I want to weave very large fabric. What are the widest rapier looms available on the market?
A: You can find Some Dornier and Picanol looms in 540cm. Seems it is difficult to go wider because of the limitation of possible lenght of rapier tapes or rapier profiles. If you want to weave wider fabric you should consider Sulzer projectile looms.
