Okamoto ACC-1632DX

OKAMOTO ACC-1632DX
NEW: 1992

NOMINAL GRINDING CAPACITY .................... 16" x 32"
MAXIMUM HEIGHT UNDER STD. 12" WHEEL
TO TABLE SURFACE ........................... 21.5"
TABLE SPEED, INFINITELY VARIABLE ............. UP TO 82' FPM
MAX. LONGITUDINAL TABLE MOVEMENT, MANUAL ..... 30"
AUTO CROSS FEED INCREMENT .................... 0.002" TO .80"
AUTO CONTINOUS CROSSFEED ..................... 4' TO 40' FPM
CROSSFEED, MANUAL, HAND FEED PER REV. ........ 0.25"
GRAD. OF HANDWHEEL ........ 0.001"
MAX. CROSSFEED, MANUAL ....................... 18"
AUTO INCREMENTAL DOWNFEED INCREMENTS ......... 0.00005" TO .0015"
POWER RAPID WHEEL POSITIONING RATE ........... 16" IPM
SPINDLE MOTOR ................................ 5 H.P.
WHEEL SIZE ................................... 12" X 1.5" X 5"
WHEEL SPEED .................................. 6,500 SFPM
GRINDING WHEEL SPEED ......................... 1,800 RPM
APPROX. MACHINE WEIGHT ....................... 8,800 LBS.

EQUIPPED WITH:
"DX" PROGRAMMABLE ELECTRONIC AUTO INCREMENTAL DOWNFEED:
-SERVO DRIVEN DOWNFEED
-AUTO INCREMENTAL DOWNFEED FOR BOTH SURFACE & PLUNGE
OPERATIONS
-DUAL RATE AUTO DOWNFEED W/COARSE & FINE SELECTIONS
-DIGITAL DISPLAY FOR VERTICAL AXIS
-SPARKOUT PASSES (0 TO 5) W/AUTO TABLE PARK AT
COMPLETION OF GRIND CYCLE
-ELECTRONIC HANDWHEEL FOR MANUAL VERTICAL MOVEMENT
W/EACH GRAD. EQUIVALENT TO .00001", .0001" OR .001"
-POWER RAPID WHEEL POSITIONING
