Okuma CNC control OSP-P200L 2,800 U/min MULTUS B400 – C 3 Axis

Turning diameter 400 mm
Turning length 1,500 mm
Y-axis travel 230 mm
B-axis 225°, positioning 0.001°
C-axis 0.001°
CNC control OSP-P200L
Main spindle speed 2,800 U/min
Main spindle diameter 150 mm
Main spindle bore 110 mm
Main spindle power 30 kW, 900 Nm
Spindle nose size 11
Total power requirement 59.5 kVA
Machine weight approx. 14.5 t
Machine footprint approx. 6.4 x 3.0 x 2.6 m
3-jaw chuck SMW KNCS-N 400 K11
Tailstock
Programmable CNC steady rest on W-axis
SMW-AUTOBLOK SLU-3 self-centering steady rest, clamping range Ø12–152 mm
Full clamping cylinder for partially hollow workpieces, bore max. Ø100 mm
In-process measuring system Renishaw for X/Z/C axes
Drill/mill spindle
Tool changer 80 tools, HSK-A63
Internal coolant supply for driven tools
Synchronized thread cutting with driven tools
Multifunction tool software
Gear hobbing software for straight and helical gears with spindle synchronization
Electrostatic extraction system
Chip conveyor
Documentation
CE certification
