Pama SPEEDMAT 2/TR 8 1004 rpm

X axis travel: 2500 mm
Y axis travel: 2500 mm
Z axis travel: 1700 mm
Rapid traverse X/Y/Z: 25 / 25 / 25 m/min
Feedrate X axis: 0.5 – 10000 mm/min
Feedrate Y axis: 0.5 – 10000 mm/min
Feedrate Z axis: 0.5 – 10000 mm/min
Control: Siemens 840 D
Workpiece weight: 6000 kg
Spindle diameter: 130 mm
Quill stroke: 700 mm
Spindle taper: ISO 50 DIN 69871 – AD
Spindle torque: 1847 Nm
Spindle speed range gear 1: 6 – 1004 rpm
Spindle speed range gear 2: 950 – 4000 rpm
Table size: 2500 x 2000 mm
Table height: 800 mm
Feed force X axis: 28000 N
Feed force Y axis: 27000 N
Feed force Z axis: 28000 N
Total power: 65 kW
Approx. 30 tool holders SK 50
Probe
Coolant system with paper belt filter
Chip conveyor
Cooler
Oil mist extraction
Clamping fixtures
Technical documentation
