Pilous CTR520E

Block Bandsaw Demonstration Machine
Robust block band saw for logs up to 60 cm in diameter, with a bimetal saw blade suitable for all types of wood,
high cutting accuracy, precise and easy height adjustment, and user-friendly operation.
Powder-coated upper section, galvanized base.
New with a 4-guided saw unit. Infinitely expandable with extension sections.
Very stable thanks to a solid welded frame. CE certified.
The original! Not a replica!

Technical Data:
Max. log diameter 600 (520) mm
Max. board width 460 mm
Motor output S6 5.5 kW (4 kW S1)
Flow motor power 0.18 kW
Max. feed speed 15 m/sec
Cutting length (basic version) 3.6 m
Saw blade length 3110 mm
Saw blade width up to 35 mm
Cutting length (optional extension section) 2.25 m
Weight 350 kg
