Polar Stanze DC / M 950-01

System die-cutter POLAR DCAutomatic in-line die-cutting uses the puncture principle.
The system die cutter POLAR DC uses the puncture principle and is suitable for all common label papers.
OnePunchRegister allows to position the cutting die in line with the printed image with just one pack.
Ultimate die-cutting precision by securing the die-cut material on all four sides.
Optimum performance with minimum staff.
Easy set-up of the die with an alternate-frame system outside the machine.
Short make-ready time by motorized precision adjustment of the cutting die within the machine.

Polar STANZE die cutter.
POLAR Die-Cutter: System die-cutter DC
Label size, max. 170 x 210 mm
Label size, min. 20 x 40 mm
Die-cut size, max. 166 x 206 mm
Die-cut size, min. 16 x 36 mm
Clamp opening, max. 125 mm
Clamp opening, min. 35 mm;
Component for ..... LabelSystems or Solo die-cutters
Voltage: 400V 50hz.
Completed with: HEBER lift.
Model: LL600-K-3 / H431-01, year 2011.
In very good condition, it has only been used a few times for testing.
