PRB Palletizer

The prb packaging systems palletizer is a vacuum pick-and-place palletizer,
ideal for automatic stacking of cartons, shrinkpacks, and similar packaged products.

Power supply : 208V 3Ph 60Hz 25Amps
Air supply : 90 PSI @ 2.5 CFM
Production speed : Up to 12 mechanical cycles/minute
Pallet sizes : 1,000×1,200 mm; U.S. 37½″×42½″; Height up to 60″
Case / pack size range : Min: 150×80×100 mm; Max: 600×610×400 mm
Empty pallet dispenser : 32″ × 43″ × 24″
Conveyors : 110″ × 1½″; Side rollers: 2 × 110″ × 2″; Infeed rollers: 23″ × 23″
Pick mechanism : 6 vacuum suction cups on 48″ robotic arm; controlled by Allen‑Bradley PLC; 3 axes + rotation; status light beacon
Overall dimensions (L x W x H) : 84'' x 90'' 110''
Weight : 3900 Lbs
