Quaser MV154E 3 Axis

Traverses XYZ: 700 x 530 x 560 mm
Rapid feedrates XYZ: 32 x 32 x 24 m/min
4th axis rotary table (rotary axis present)
Control: Heidenhain TNC620
Bar capacity: —
Swing: —
Spindle motor power: 18.5 kW
Spindle speed: 12,000 rpm
Tool change capacity: 30 station
Maximum tool diameter: 76 mm
Maximum tool diameter with empty adjacent pockets: 125 mm
Maximum tool length: 280 mm
Maximum tool weight: 7 kg
Table size: 900 x 500 mm
Minimum–maximum height under spindle: 150–710 mm
Maximum workpiece weight: 500 kg
Machine dimensions: 2465 x 2600 x 3000 mm
Machine weight: 6400 kg

Machine Equipped With
4th axis interface
4th axis rotary table
Coolant
Interlocked guards
Low volt light
Swarf conveyor
Through spindle coolant
Tool setter
