Rima RS-10S

Ref : 2716282-4-AW
Condition : Used
Manufacturer : Rima
Model : RS-10S
Year(s) : 2005
Quantity : 1
Location : Seller or machines location:
AMERICA North (USA-Canada-Mexico)

Compensating Stacker
“A“ Dimension 102 mm (4.00“) (opt. 89 mm (3.50“)) 320 mm (12.63“)
“B“ Dimension 152 mm (6.00“) (opt. 127 mm (5.00“)) 470 mm (18.50“)
“D“ Dimension limited by “A“ & “B“ 520 mm (20.50“)
Thickness 1 mm (0.04“) 32 mm (1.25“)
Speed product permitting 20,000 products per hour

Stack height RS 1012S/1212S upper bin
total stack
127 mm (5.00“)
235 mm (9.25“)

Stack height RS 10 upper bin
total stack
127 mm (5.00“)
330 mm (13.00“)

Infeed height RS 10 var. between 660 mm (26.00“) 990 mm (39.00“)
Infeed height RS 10 var. between 750 mm (29.50“) 1079 mm (42.50“)
Product orientation: Spine leading (prefered)
Delivery height 876 mm (34.50“)
Input power RS 10S: 1.5 KVA (standard) / 3 KVA (servo), 50/60 Hz, 3 ~ (voltage: see Technical Specification)
Air requirement RS 10S: 45 l/min (1.6 CFM) (normal) / 76 l/min (2.7 CFM) (maximal) @ 5,5 bar (80 psi)
Weight: 1,100 Lbs
Noise level DIN 45635 Section 27 85 dB(A
Dimension – 77x34x72
