Rotatek FIS30

Size: 330 mm
Machine: Label and packaging finishing machine
Type: - Rotatek off line finishing 330

Technical data:
Web width:
- Maximum web width: 350 mm
- Minimum web width: 150 mm
Printing cylinder: - Print cylinder circumference for semi-rotary operation: 25.5"
Die-cutting size:
- Magnetic cylinder circumference for semi-rotary operation: 25.5"
- Die-cut format in rotary mode: 13" to 25.5"
- Die-cut format in semi-rotary mode: 2" to 24.5"
Print format:
- Flexo print format in rotary mode: 13" to 25.5"
- Flexo print format in semi-rotary mode: 2" to 24.5"****
Printing width: - Maximum print width: 330 mm

Print repeat length:
- Variable print repeat length in increments of 0.1 mm (as with Digicon)
- Screen printing repeat length (semi-rotary only): 400 mm
- Hot foil stamping print length, semi-rotary: 400 mm
Speed:
- Max. mechanical speed in semi-rotary mode: 65 m/min*
- Max. mechanical speed in semi-rotary mode: 25 m/min**
- Max. mechanical speed in rotary mode: 150 m/min***
Registration tolerance: - Registration tolerance: �0.15 mm

Equipment:
- Offset 1x
- Flexo 1x, lamination/delamination
- Die-cutting with magnetic cylinder
- Hot foil stamping (round)
- Flat screen printing
- Matrix stripping (waste lattice removal)
- Slitting cassette with shear blade
- 2-spindle rewinding
- Cross cutter (sheeter)

Condition: How it stands and goes
Output: Output (m): 203,720,021
Air supply: Compressed air supply is required on-site
Power supply: This Machine Is Configured for 400 V, 50 Hz
Important: Connection requirements of any power utility note!
CE mark: The machines bear the CE mark
Specifications: Technical data and illustrations are subject to change.
