Royal IHC BEAVER 45

Cutter suction dredger
High-efficiency dredging system
Fuel efficient design
Low maintenance design
Advanced diagnostics
Ergonomic operator layout
Cutter Special pump
Large ball passage pump
Single diesel engine power distribution
Enhanced safety systems
Class certified
Floating pipeline included
HDPE floating pipe length 1000 m
Designed for one-man operation
Transportable design
Fully assembled and tested prior to delivery
Ready for operation upon arrival
LED lighting
Hydraulic auxiliary systems
Fresh-water cooling system
Deck crane
Production monitoring capability
Automation capability
Positioning system capability
Air conditioning option
Harbor generator option

Vessel Type: Cutter suction dredger
Standard Dredging Depth: 10.0 m
Suction Diameter: 450 mm
Discharge Diameter: 450 mm
Main Engine Power: 895 kW
Main Engine Speed: 1800 rpm
Cutter Power: 110 kW
Dredge Pump Type: HRCS2 108-23-45
Ball Passage: 225 mm
Pump Wear Material: White iron
Specific Fuel Consumption: 205.9 g/kWh
Cutter Diameter: 1330 mm
Maximum Cutter Speed: 34 rpm
Swing Winch Line Pull: 57 kN
Swing Winch Line Speed: 25 m/min
Swing Wire Diameter: 18 mm
Swing Wire Length: 100 m
Anchor Weight: 360 kg
Number of Spuds: 2
Spud Length: 13.85 m
Spud Diameter: 457 mm
Spud Weight: 2260 kg
Spud Hoisting Force: 100 kN
Spud Stroke Per Cycle: 3.5 m
Electrical System Voltage: 24 V DC
Battery Capacity: 400 Ah
Deck Crane Capacity: 20 kN
Deck Crane Outreach: 2.8 m
Length Overall Ladder Raised: 26.60 m
Length Over Pontoons: 16.96 m
Beam: 6.99 m
Depth: 2.01 m
Mean Draught Full Bunkers: 1.40 m
