Sangiacomo 125 T DM 125 to

SANGIACOMO 125 T DM
2016

Pressure125 to
Pressure1250 kN
Fixed table: length1300 mm

Number of strokes:
stepless
from50 s/min
up to120 s/min

Adjustment of the slide3 mm

Slide surface:
Width1300 mm
depth800 mm

Adjustable stroke:
from16 mm
up to200 mm

Max. tool-weight300 kg
Air connect5 - 6 bar
Voltage 50 Hz 3x400 Volt
Power24 kW
Machine's weight about14000 kg

Overall dimensions machine:
Length1910 mm
Width1250 mm
Height3920 mm

Various accessories:
Belt feeding
MEDIUM SRF 200 U5
Band width
200 mm
Sheet thickness
4.5 mm
Stock reels
SOPREM
Workpiece conveyor
Sound insulation cabin
Déclanchement à deux mains
