SCM Cyflex H800

Documentation available No
CE marking present Yes
CE certificate present No
Main motor power [kW] 2.2
Number of controlled axes [pcs] 12
Working range X [mm] 3050
Working range Y [mm] 800
Working range Z [mm] 60
X-axis max stroke [mm] 1040
Y-axis max stroke [mm] 1030
Z-axis max stroke [mm] 100
Number of milling spindles [pcs] 8
Spindle diameter [mm] 10
Min. spindle speed [rpm] 1000
Max. spindle speed [rpm] 4000
Horizontal drilling unit Yes
Horizontal drilling spindles [pcs] 6
Max. drilling depth [mm] 18
Vertical drilling unit Yes
Vertical drilling spindles [pcs] 8
Max. drilling depth [mm] 30
Saw unit present Yes
Voltage [V] 400
Current consumption [A] 10
Transport dimensions 2300mm x 1950mm x 1850mm (l x w x h)
Transport weight [kg] 1240kg
Transport packages [pcs.] 1
