Siemens ACUSON Juniper Ultrasound System

The Siemens ACUSON Juniper is a versatile, premium-performance ultrasound system
built on a completely new platform engineered from the ground up.
Designed to deliver high-fidelity transmit and receive acoustic signals that
greatly reduce noise, it provides premium image quality and industry-leading elasticity solutions.
Small on the outside yet powerful on the inside, the ACUSON Juniper empowers clinicians to
image virtually every patient regardless of size, weight, or condition, delivering the
clinical information needed for confident decision-making across departments.

Designed to image every patient
With its clinical versatility and industry-leading tissue elasticity imaging,
the ACUSON Juniper enables you to expand your ultrasound clinical and
service offerings across virtually all patient and case types.
Its wide variety of clinical solutions and fast image acquisition improve
diagnostic confidence across radiology, interventional radiology, urology, cardiovascular,
orthopedic, and obstetrics/gynecological imaging.
The system supports a comprehensive suite of Shared Services, Cardiac,
and Women’s Health clinical applications.

Compact footprint and effortless maneuverability
Up to 36% smaller than other systems in its class, fitting into virtually any hospital room.
Weighs only 76 kg (168 pounds), making it one of the lightest and
easiest-to-maneuver ultrasound systems in its class, weighing an
average of 27% less than other systems in its class.
Front and back handles for effortless maneuverability, allowing the system to
be pulled from either the front or the back.
Bi-directional locks enable moving the system easily from one location to another.
Among the quietest systems in its class, with a sound pressure of only 28 decibels,
40% quieter than the average ultrasound system, creating a comfortable,
stress-free room environment.

Ergonomics and control panel
21.5-inch LED monitor, highly adjustable toward, away, and side-to-side
for optimal ergonomic positioning.
13.3-inch high-resolution, tiltable, highly customizable capacitive touch panel
with rapid-response technology for quick and accurate key selection.
Simple, intuitive control panel with customizable height, angle, and keys,
supporting greater workflow personalization.
90-degree right and left rotation for flexible transducer connector positioning,
adaptable to space availability and patient bed location.
Customized disposable skin keeps the control panel clean and sterile.
Purposeful cable management hooks (several available) for a clean, cable-free environment.
Utilities storage basket, magnetic storage bin, and transducer holders; space
for easy installation of peripherals.
QuikStart Standby Mode for quick boot-up time and maximum productivity.

Connectivity and hardware
6 ports total: 5 active transducer ports plus 1 dedicated CW (pencil/continuous-wave)
port for cardiac applications, and 2 physio ports.
ECG cable connector and auxiliary physio port.
DVD writer.
Windows 10 operating system.
Ultrasound system security with virus protection.
DICOM 3.0 Connectivity, DICOM Modality Worklist, DICOM MPPS (Modality Performed Procedure Step), and DICOM Structured Reporting.

Imaging technologies
B-mode: high contrast resolution and complete image uniformity for full diagnostic quality.
New front-end, beamformer, and back-end engines improve contrast resolution,
penetration, sensitivity, and specificity.
eSieImage Multiparametric Optimization: excellent contrast resolution and visualization
of subtle tissue differences without manual gain adjustments.
Dynamic TCE tissue contrast enhancement technology for improved tissue differentiation
and border detection.
Advanced SieClear spatial compounding.
Color Doppler: exceptional color resolution with improved physiological representation of color.
Dynamic Persistence and color Auto Flash Artifact Suppression technologies reduce
motion artifacts and noise while enhancing color sensitivity.
Clarify Vascular Enhancement (VE) technology.
Shear wave elastography imaging with industry-leading, best-in-class elasticity solutions.
Virtual Touch Quantification (VTq): one-touch quantitative elastography analysis
providing reproducible, reliable, and detailed tissue stiffness information.
eSie Touch Elasticity Imaging.
Enhanced Needle Visualization.
3-Scape 3D and 4D Imaging for detailed volumetric representation of pathology.
SieScape panoramic imaging.

Applications and clinical packages
syngo Velocity Vector Imaging (VVI): cardiac strain analysis package to
assess myocardial motion and mechanics, quantifying Global Longitudinal Strain (GLS),
Global Circumferential Strain (GCS), and Global Radial Strain (GRS).
Stress Echo.
Left Ventricular Opacification Contrast (LVO).
DTI Doppler Tissue Imaging (for cardiac).
eSie Left Heart (LH) Measurement Package.
Physio Module and Cardiovascular package.
syngo Arterial Health Package (AHP).
syngo Auto OB Measurements and syngo Auto Follicle Measurements.
eSie Measure Workflow Acceleration Package.
eSieScan Workflow Protocols for consistency and repeatability, guiding the user on required views.
eSieLink and comprehensive Measurement & Report (M&R) packages.

Transducers
The ACUSON Juniper offers a comprehensive suite of 19 transducers covering a
diverse range of clinical applications, including single-crystal technology such as
the 5P1 cardiac transducer and the 5VT transesophageal transducer.

Standard probes: 5C1, 8VC3, 10MC3, 12L3, 11L4, 5P1, CW2, CW5.
Additional probes: 7C2, 11M3, 9VE3, 9MC3, 16L4, 13L4, 18H5, 5VT, 8V4, 10V4, CW8.
Service and connectivity solutions
The ACUSON Juniper is supported by the Siemens Healthineers services portfolio,
including Smart Remote Services (SRS), PEPconnect, and teamplay Fleet, along with UpTime,
UpSpeed, UpSkill, UpLift, and UpTeam service offerings, plus comprehensive Service Plans.
