1/1
SMG HZPU 200-1250/2000 + 80 ton 200 ton
Ref :
2718520-3-CP
Condition :
Used
Manufacturer :
SMG
Model :
HZPU 200-1250/2000 + 80 ton
Pressure :
200 ton
Year(s) :
-
Quantity :
1
Location :
Seller or machines location:
EUROPE (Western and Northern)
EUROPE (Western and Northern)
SMG HZPU 200-1250/2000 + 80 ton
Capacity 200 ton
Max ram adjustment 650 mm
Drawningspeed 400 mm/sec
Workingspeed 36 mm/sec
Returningspeed 260 mm/sec
Passage between uprights 1260 mm
Max distance between table - ram 1000 mm
Dimensions of the table 1250 x 1000 mm
Max counter-pression table 80 ton
Electric motor (power) 50 hp
Weight 25 ton
Additional info
stroke of counterpressure in table: 325 mm
downward stroke in ram: 290 mm
