steam recovery boiler 14.5 t/h
Ref :
2796649-8-CP
Condition :
Used
Manufacturer :
-
Model :
steam recovery boiler
Capacity :
14.5 t/h
Year(s) :
2015
Quantity :
1
Location :
Seller or machines location:
EUROPE (Western and Northern)
EUROPE (Western and Northern)
capacity 16 t/h, waste heat boiler: 14.5 t/h
type Gas Turbine Plant / Vitomax ADHZ • UE 15.0 Boiler
Electrical Power 2000 kW
Peak Load Boiler 16 t/h
Waste Heat Boiler14.5 t/h
Module A – Steam
PS = 31.4 bar(g), TS = 465 °C
Module B – Water
PS = 39.0 bar(g), TS = 120 °C
Module C – Condensate
PS = 31.4 bar(g), TS = 465 °C
Module D – Gas
PS = 16.0 bar(g), TS = 50 °C
Pressure (Pmin / Pmax) 0 / 31.4 bar(g)
Temperature (Tmin / Tmax) 10 / 238.2 °C (Pressure Body) / 10 / 298 °C (Combustion Chamber)
Content (Full) 28 700 L / 400 L
Medium Water / Steam
Heated Surface 575.4 m²
Max. Steam Production 15 000 kg/h
Max. Net Capacity 58.1 / 69.5 kW
