Sumitomo C1250 385 T

Type All Electric
Clamping Force Tonnage 385 T
Shot Volume (PS) 24.4 oz
Screw Diameter 2.48"
Maximum Injection Pressure 25033 psi
Screw Speed High Torque 320 rpm
Plasticizing Capacity (PS) STD 10,224 oz
Tie Bar Distance H 29.13"
Tie Bar Distance V 27.95"
Platen Dimension H 43.13"
Platen Dimension V 40.16"
Clamp Stroke 27.56"
Maximum Daylight 53.94"
Mold Height Min 15.94"
Mold Height Max 26.38"
Ejector Force 6.6 T
Ejector Stroke 5.91"
Power supply Volts 460
Hours 6,285 hr.
Control CNC (NC5)

Equipped With
Features: High Speed
- Robot Interface
- 5 additional machine condition output signals
- Pneumatic Ejector Needle Valve Drive Circuit
- 2 additional dry contacts for Semi Automatic & Coo
Features: Valve Gate
