Tauler PrintLam CTI 75 Automatic laminator

It has a high quality of laminating layer application, even at maximum productivity.
Technical specifications:
max. sheet size 750×1050 mm
min. sheet size 200 (190)×250 mm
maxi. mechanical speed 30 m/min
productivity up to 4,000 sheets/hour
The material used is 110-600 g/m2
self-loading slipway height 900 mm
the height of the slipway on the laying is 530 mm
installed capacity 9.2 kW
voltage 3×380 V, 50 Hz

Equipment:
automatic vacuum self-priming with pneumatic head
control of the passage and double sheet
sheet alignment, front stamps
the function of stopping the machine (by photo sensor) in case there is no paper in the stack
thermal calendering (hot lamination) using an oil-filled heating cylinder
pneumatic pressure roller
film mounting bracket
trimming excess foil at the edges
cutting roller and pressure wheel for easy separation of products
boxed layout
continuously adjustable machine speed using a frequency converter (inverter)
electronic PLC control.
It can be seen in production.
