Tomey AL-3000

Features:
Axial Length Measurements and Waveform Display
Corneal Thickness Measurement
IOL Power Calculation
Ultrasound Technology
STN Colored Touch Screen LCD
Compact & Lightweight
Automatic Tone-Assisted Measurement
Contacts & Immersion Mode
6 IOL Calculation Formulas
Multipoints Pachymeter Map
Wide Measurement Range
Solid State Probes

Specification & Options
Biometry / IOL calculations
Range:
Axial length: 15 ~ 40 mm
ACD velocity: 1.8 ~ 7 mm
Lens thickness: 2 ~ 6 mm
Minimum display unit: 0.01 mm
Accuracy: ± 0.1 mm
IOL calculation: SPK II, SPK/T, HOLLADAY, Hoffer Q, HAIGIS optimized,
HAIGIS standard, SHOWA

Pachymetry
Range: 150 ~ 1,500 μm
Minimum display unit: 1 μm
Accuracy: ± 5 μm

Dimensions and Electric Requirement
Dimensions: 298(W) x 285(D) x 263(H) mm
Weight: Approx. 5kg (11.0 lbs.)

" Power supply: AC 100 ~ 240 V (adjusts automatically) "

Frequancy: 50 / 60 Hz
Consumption power: 45 ~ 50 VA

Configuration
Tomey AL 3000 Biometer & A-Scan Pachymeter
with a pachy meter probe and the A scan slit-lamp.

Condition
Patient ready
