Topcon 3D OCT-1 Maestro

Up for sale used Topcon Maestro 3D OCT-1 & Fundus Camera Optical Coherence Tomography.
Comes with Brand New Win 10 CPU all in 1 system with ImageNet software,
6 months warranty and 30 days money back guarantee.

User can choose between a Semi-auto capturing mode,
in which the system will complete alignment, focus and optimise the view,
or, according to specific pathology or patient condition, use it manually.
The system can capture small pupils with diameter of 2.5 mm
In case there is opacity in the eye due to cataract, the operator can switch on
the cataract mode with one finger touch. The cataract mode will automatically move
the scanning position on the upper/lower (or L/R) area.
The 3D OCT-1 Maestro allows for rich analysis functions for Macula, Glaucoma or Anterior.

Based on a long history of product innovation, including the first to combine SD OCT
with color fundus photography, Topcon has set the bar for providing patient friendly,
easy to use and completely automated comprehensive OCT for today’s eye care needs.

Features
Fully automated operation
Rich analysis and report functions
Compact & space saving design
EN VIEW OCT Imaging
True color fundus photography
Superb OCT technology
Network and DICOM connectivity

Observation & Photography of Fundus Image
Scan mode Color, red-free
Picture angle 45°/30° or equivalent (digital zoom)
Operating distance 34,8mm (in fundus photography)
62,6mm (in anterior segment photography)
Photographable diameter of pupil 45°: Ø 4.0mm or more
Small pupil diameter: Ø 3.3mm or more

Observation & Photographing of the Fundus / Anterior Segment Tomogram
Scan range (on fundus) Horizontal direction 3 ~ 12mm, Vertical direction 3 ~ 9mm
Scan range (on cornea) Horizontal direction 3 ~ 6mm, Vertical direction 3 ~ 6mm
Scan speed 50,000 A-Scans per second
Lateral resolution 20μm
In-depth resolution 6μm (digital resolution 2,6μm)
Photographable diameter of pupil Ø 2.5mm or more
Internal fixation target Dot matrix type organic EL (The display position can be changed and adjusted. The presenting method can be changed.)

Electric Rating
Source voltage AC 100-240V / 50Hz-60Hz
Power input 70-150VA

Dimensions and Weight
Dimensions (W x D x H) 307-442 x 472-668 x 518-722 mm
Weight 21kg
