Tornos Tornos Bechler Fanuc PNC Deco 6000 1/min BECHLER MultiDeco 20/6 18Axis

TORNOS BECHLER MultiDeco 20/6
Control: Tornos Bechler Fanuc PNC Deco
New in: 2001

Maschine on approx. (hrs): 77725
Shifts Maschine on approx. (hrs): 2-3 shift

TURNING
18Axis
Max. turning diameter 20 mm
6 pc. Main spindle/-s
Max. speed main spindle 6000 1/min
Max. power main spindle at 10-40/100% duty ratio 15 kW

FURTHER EQUIPMENT
Fully enclosed work area
Light in working area
Preparation for central oil-/emulsion mist extraction unit
Slat band chain chip conveyor MAYFRAN Consep 2000
Machine operates/operated with oil
Coolant unit
Automatic CO2-fire extinguishing system
Bar loader/magazine ROBOBAR MSF 522/6

GENERAL TECHNICAL DATA
Total power requirement 43 kVA
Machine dimensions (LxWxH) approx. 3500x1600x1950 mm
Machine weight approx. 8500 kg

Remarks
- Position 1/2/3/4/5: identically equipped with CNC-cross slide X/Z (longitudinal unit Z)
- Position 6: CNC-plunge cut, back side drilling unit, opposing spindle
- Length measuring system
- 4 Stck. Bohraparate mit Werkzeugaufnahme
- 1Stck.Schnellbohrspindel mit Werkzeugaufnahme
- 1 Stck. Gegenspindel
- 3 Stck. Drehhalter
- 1Stck. Abstechhalter
- 1 Stck Hinterbohrhalter
- 2 Stck Bohrerbruchtaster
- 1 Stck Längenmeßtaster mit Erstteilsortierung
