TOS SKIQ 25 - 2 RAM HYDRAULIC CHUCK DIAM2500 MM

Ref : 2717129-3-GO

Condition : Used

Manufacturer : TOS

Model : SKIQ 25 - 2 RAM

Short Description : HYDRAULIC CHUCK DIAM2500 MM

Year(s) : -

Quantity : 1

Location : Seller or machines location:
EUROPE (Western and Northern)

TOS SKIQ 25 - 2 RAM

HYDRAULIC CHUCK DIAM2500 MM
MAX TURNING DIAM2900 MM
MAX LOAD CAPACITY25 TON
MAX PIECE HEIGHT1640 MM
NR OF RAM2
RIGHT RAM TRAVEL1000 MM WITH ATC
LEFT RAM TRAVEL1060 MM
RAM SECTION180 X 200 MM
CROSS RAIL VERTICAL TRAVEL1000 MM
SPINDLE MOTOR POWER80 KW
SPINDLE SPEED ROTATION200 RPM
GEAR NUMBERS2
ATC15 POSITIONS
CNCSIEMENS 840 C

OTHER DETAILS
UNDER POWER
