TOS SKS 25 Maximum Turning Diameter: 2900 mm

Ref : 2800521-3-GO

Condition : Used

Manufacturer : TOS

Model : SKS 25

Short Description : Maximum Turning Diameter: 2900 mm

Year(s) : 1997

Quantity : 1

Location : Seller or machines location:
EUROPE (Western and Northern)

VERTICAL TURNING LATHE (VTL)
Siemens 840C CNC Control
Hydraulic Chuck Diameter: 2500 mm
Maximum Load Capacity: 25 Ton
Maximum Workpiece Height: 2000 mm
Ram Travel: 1000 mm
Ram Section: 180 x 200 mm
Cross Rail Vertical Travel: 1300 mm
Spindle Speed: 200 RPM
Spindle Motor Power: 63 kW
Gear Numbers: 2
C Axis
Milling Spindle Motor Power: 15 kW
Milling Spindle Speed: 3000 RPM
ATC for Turning: 15 Positions
ATC for Milling: 24 Positions ISO 50
C Axis Equipped
Number of Rams: 1
