Toyama DP-103C

• Method: decompression with chamber wall heating
• Operating Temperature Range: 40–200 °C
• Operating Vacuum Range: 101–0.1 kPa (760–1 Torr)
• Temperature Adjustment Accuracy: ±1.0 °C (at 200 °C)
• Interior Material: stainless steel plate
• Exterior Material: cold rolled steel plate with chemical-proof coating
• Insulating Material: glass fiber
• Heating Method: decompressed chamber wall direct heating
• Heater Power: 14.4 kW
• Observation Window: toughened glass with resin protection panel
• Vacuum Gauge Type: pointer
• Vacuum Gauge Range: −100–0 kPa
• Vacuum Pump Installation Room: included
• Temperature Control: 3-segment PID
• Temperature Setting Method: function menu key with up/down keys
• Temperature Display: measured temperature, green 4-digit LED
• Timer Range: 1 min–99 h 59 min
• Timer Range: 100 h–999 h 50 min
• Timing Function: wait function included
• Operation Function: fixed temperature auto start
• Operation Function: auto stop
• Operation Function: program operation
• Program Mode: 3 segments, 30 steps
• Program Configuration: 30 steps ×1
• Program Configuration: 15 steps ×2
• Program Configuration: 10 steps ×3
• Additional Function: deviation correction
• Additional Function: key lock
• Additional Function: power outage compensation
• Heater Circuit Control: SSR driving
• Sensor Type: K thermocouple
