TRAILING SUCTION HOPPER DREDGER (1300 CY) Hopper capacity: 1,300 CY

Hopper capacity: 994 m3
Bottom dump capability
Bow discharge capability
Max effective dredging depth: 1.651 m
Length overall: 60 m
Width: 12.43 m
Depth: 5 m
Draft: 4.45 m
Gross tonnage: 760 t
Class: ABS
Next SS: January 2027
Main engines: 2 x Niigata ZP-D8 Z Drives
Main engines rebuilt: 2021
Main engine hours: 1154 h
Main engine hours: 1205 h
Service generators: 2 x Caterpillar 3306
Service generators rebuilt: 2021
Generator hours: 1588 h
Generator hours: 1626 h
Dredge generator: Caterpillar C27
Dredge generator hours: 14,500 h
Dredge motor: 700 hp
Suction head: 1.62 m
Suction pipe: 0.56 m
Discharge pipe: 0.51 m
Air compressors: 2 x Quincy 350L
Accommodation capacity: 15 beds
Beds first floor: 9
Beds second floor: 4
Beds third floor: 2
Vertical distance bottom to top of mast: 22.67 m
Light draft forward: 1.61 m
Light draft aft: 2.65 m
Light draft average: 2.13 m
Loaded draft average: 4.45 m
Lightship displacement: 919.13 LT
Summer free displacement: 2470 LT
Summer free DWT: 1506 LT
Number of dragarms: 1
Max digging depth at 45 deg: 19.81 m
Available pump power: 1 x 700 hp
Pump RPM dredging: 290
Pump RPM pumping out: 360
Fuel tank capacity: 95 m3
Fresh water tank capacity: 28 m3
