Tsugami Fanuc 0i-TD 6,000 RPM B0385 5 Axis

Number of Axes: 5
Control: Fanuc 0i-TD
Guide Bushing Configuration
Bar Capacity: 38 mm
Working Bar Stock Diameter: 8 - 32 mm
Spindle Hole Diameter: 38 mm
Main Spindle Speed: 200 - 6,000 RPM
Sub Spindle Speed: 200 - 7,000 RPM
Spindle Motor: 7.5 / 11 kW
Live Tool Speed: 5,000 RPM
Main Spindle Drilling Capacity: 13 mm
Main Spindle Tapping Capacity: M12
Back Spindle Drilling Capacity: 12 mm
Cross Drilling Capacity: 10 mm
Cross Tapping Capacity: M8
Tool Spindle Slotting Cutter Capacity: 45 mm
Maximum Headstock Stroke: 250 mm (9.84")
Live Tool Positions: 5 - 10
Power: 7.5 HP
Main and Back Simultaneous Machining
MP H08 Coolant System
2,000 PSI Coolant System
1,000 PSI Coolant System
Tri-Mist 850 Mist Collector
Edge 3-36 Turbo Chip Conveyor
Main Collets Included
Guide Bushings Included
FMB Turbo 3-38 Bar Feeder
Footprint: 99.2" x 52.9" x 77.5"
Machine Weight: 4,600 kg (10,140 lbs)
