UROLA URBI2, Blow Moulder

Technical data
Capacity: Maximum 3,200 bph
Formats: Maximum container dimensions 120 mm diameter × 350 mm height
Application: Production of PET containers
Configuration: 2 cavities

Installed Power
Preform rotation motor: 0.18 kW
Clamping press motor: 7.5 kW
Stretching motor: 3.0 kW
Transfer arm motor: 1.3 kW
Preform heating oven: 32.0 kW
Preform feeder: 0.36 kW
24 VDC power supply (10 A): 1.0 kW
Air reflector fan: 0.75 kW
Neck cooling fan: 0.75 kW
Lubrication pump: 0.07 kW
Container evacuation: 0.09 kW
Intermittent chain rotation: 0.18 kW

Cooling Circuit
Water inlet temperature: 10–20 °C
Water consumption: 2 m³/h
Operating pressure: 4 kg/cm²
Cooling capacity: 10,000 kcal/h

Pneumatic System – Low Pressure
Operating pressure: 7 kg/cm²
Air consumption: 800 l/min

Pneumatic System – High Pressure
Operating pressure: 38 kg/cm²
Air consumption: 5,000 l/min
