UV Detector

The ultraviolet-visible dual-wavelength detector features high sensitivity and a wide linear range. The deuterium lamp and tungsten lamp are interchangeable.
Touchscreen design makes operation simple. Wavelength multi-point correction Digital output and analog output can be replaced at any time. The firmware program can be updated online, with LAN connection and stable data transmission.
The specific power-off protection function enables the instrument to promptly alarm and automatically stop operation according to the set program.

Product parameters
Model: EUD0010
flow cell
Model: Analysis
Interface size: 1/16”
Material: SSTor PEEK
Optical path: 10mm
Wavelength accuracy: ±1nm
Wavelength repeatability: 0.2nm
Wavelength range & light source: 190-700 deuterium lamp
Min. detection limit(Naphthalene methanol solution): ≤4*10⁻⁹g/mL
Bandwidth: 8nm
Detection range: (0-5) AU
Baseline noise (static) : 0.75*10⁻⁵ AU
Baseline drift (static): 1*10⁻⁴ AU/h
Control mode: RS232 or LAN
Display : 5.0-inch touch screen
Power supply: AC 100-240V,50/60Hz
Power: 75W
Size（L*W*H): 368*260*140
Weight(kg): 6.9
