Victor FANUC 0i-MF 8000 rpm KB5164 2 Axis

Victor KB5164
Year: 2002

X-axis travel: 700 mm
Y-axis travel: 480 mm
Z-axis travel: 510 mm
Spindle-to-column distance: 545 mm
Spindle-to-table distance: 150–660 mm
Table size: 800 x 460 mm
T-slot size: 4 x 18 x 100 mm
Max table load: 500 kg
Spindle taper: BT-40
Spindle motor power: 7.5 kW
Spindle speed: 8000 rpm
Rapid traverse (X/Y/Z): 36/36/36 m/min
Optional rapid traverse (X/Y/Z): 42/42/30 m/min
Cutting feed rate: 10 m/min
Axis motor power (X/Y/Z): 3/3/3 kW
Ballscrew diameter and pitch (X/Y): 40 mm, pitch 16
Ballscrew diameter and pitch (Z): 40 mm, pitch 12
Max tool length: 250 mm
Max tool weight: 8 kg
Tool magazine capacity: 24 tools (disc type)
Max tool diameter: 80 mm
Tool change time (T-T): 1.5 sec
Tool change time (C-C): 4.9 sec
Pull stud angle: 90° (optional 45°)
Power requirement: 23 KVA
Air pressure requirement: 5.5–6.5 kg/cm²
Coolant tank capacity: 240 liters
Control unit: FANUC 0i-MF
Machine footprint: 2123 x 2350 mm
Machine height: 2500 mm
Machine weight: 4100 kg
Linear guideways
