Wabash CMG50H-24 50 tons

WABASH CMG50H-24
2022

Maximum capacity 50 tons
Maximum stroke 8″
Maximum daylight 24″ adjustable to 14″
Bed and ram area 34″ x 25″ (right to left x front to back)
Distance between posts 27.5″ x 17.5″ (right to left x front to back)
Usable bed area 27.5″ x 25″ (right to left x front to back)
Heated platens 24″ x 24″
Maximum platen temperature 650 °F
Floor to bed height 41″
Ram rod diameter 5″
Cylinder bore 7″
Column diameter 2″
Speed 80 / 5 / 75 inches per minute
Positioning control Proximity switches
Electric motor 3 HP, 230/460V, 3-phase, 60Hz
Hydraulic reservoir capacity 20 gallons
Hydraulic system Dual gear pump, self-contained
Controller Allen-Bradley MicroLogix 1400
Touchscreen PanelView-800 4″
Equipped with Thermal Transfer Products 159.00009 water-cooled heat exchanger
Approximate dimensions 60″ x 60″ x 78″ high
