Yamazaki YZ-500WR Vertical 2,000 rpm

X-Axis Travel: 1,250 mm
Y-Axis Travel: 550 mm
Z-Axis Travel: 520 mm
Distance Spindle to Table: 140–660 mm
Number of Controlled Axes: 2 (X, Y)
CNC Control: FANUC 32i-MB
Control Panel: General-purpose / guidance type
Table Size: 1,600 × 500 mm
Maximum Workpiece Weight: 600 kg
Spindle Speed: 2,000 rpm
High-Speed Spindle Specification: 3,000 rpm
Spindle Control: Inverter control
Spindle Taper: BT50
Tool Attachment/Detachment: Pull stud type BT50
Chip Conveyor: Chip coil conveyor, internal
Table Splash Guard: Equipped
Machine Partition: Partition type
Cutting Fluid Device: Not equipped
Required Floor Space: 3,350 × 2,070 mm
Machine Height: 2,475 mm
Machine Weight: 4,700 kg
