Used Twisting / Two For One (TFO)
515 results168 spindles, pitch 205 mm, pot-ø 157 mm, feeding: assembling cones 6-7“ delivery: 6“ con. tubes 4°20 or cylin Year(s) : 1991 Location : EUROPE (Western and Northern)
Price : On request
More detailsgeneral overhault in 2008, 132 spindles, 6” traverse, pot diameter 185 mm, feeding: Year(s) : 1990, 2008 Location : EUROPE (Western and Northern)
Price : On request
More detailsBauart 4.60, 88 spindles feeding: assembling cones 8-10”, delivery: 10“ traverse cones 270-290 mm length airth Year(s) : 1987 Location : EUROPE (Western and Northern)
Price : On request
More details2 x 36 = 72 spindles feeding pot-diameter 300 mm inside high 300 mm for feeding assembling cones 10” and 12” t Year(s) : 1987 Location : EUROPE (Western and Northern)
Price : On request
More detailsFOUR MACHINES ARE IN PERFECT WORKING CONDITION PACKAGED AND READY TO SHIP Location : Russia
International Socks Ltd
Jun, 30
for Nm 10/2 until 75/2 turns/m 123-2800 160 spindles pitch 198 mm speed up to 12.000 t/min. – 24.000 twist tur Year(s) : 1999 Location : EUROPE (Western and Northern)
Price : On request
More detailsyear 1996, Bauart 5.10 general overhauled in 2018, 144 spindles feeding: assembling bobbins 6-7”, tubes leng Year(s) : 1996 Location : EUROPE (Western and Northern)
Price : On request
More detailstype 2 x 36 = 72 spindles, ring-diam. 145 mm with 3 flange-bobbins each spind Year(s) : 1996 Location : EUROPE (Western and Northern)
Price : On request
More details2 x 94 spindles pitch 150 mm ring-Ø 113 mm, tubes 450 mm 3 cylinders each side outstanding creel each side Year(s) : 1976 Location : EUROPE (Western and Northern)
Price : On request
More details-For heavy industrial yarn -n.60 heads -two-sided -ring diam.140 x16.7 mm -pitch 270 mm -gauge 225 mm -S and Z Year(s) : 2008 Location : EUROPE (Western and Northern)
Price : On request
More details1 twister position for coarse counts with winder suitable for all types of material for 5.000 to100.000den 24 Year(s) : 2015 Location : EUROPE (Western and Northern)
Price : On request
More detailsZ/S 10-210 t/m speed 6000rpm dtex1100-56000 42 spindles with creel for 6 bobbins ring dia 300mm package height Year(s) : 2008 Location : EUROPE (Central and Eastern)
Price : On request
More detailsBARMAG DD2000 TWISTING MACHINE 24 HEAD: YEAR: 2003 1 POS MISSING, POT DIAMETER 33CM BARMAG DD2000 TWISTING MA Year(s) : 2001, 2003 Location : AFRICA
Price : On request
More detailsNo. of Spindles 144-Spindles Spindle Type S-166 (165mm pot dia.) This model is designed for applic Year(s) : 1996 Location : ASIA (North East)
Price : On request
More detailsFor sale 12 ICBT TFO DT360 128 positions each Course 220 mm Tubes 230 mm Pots 140 mm Year(s) : 1993 Location : EUROPE (Western and Northern)
Price : On request
More detailseach machine with 72 positions made for twisting smaller titer of yarn (from 230 dtex up to 900 dtex). For tu Location : EUROPE (Central and Eastern)
Price : On request
More details60 take up spindles, ring dia.220 mm. positive drive, 3 ends feeding 180 positions. Location : EUROPE (Western and Northern)
Price : On request
More details(4) Type CC3 - 160 positions ea. - 2007 year (3) Type CC3 - 120 positions ea. - 2005 year Running Tire Cord Year(s) : 2005, 2007 Location : AMERICA North (USA-Canada-Mexico)
Price : On request
More details48 spindles, including all parts and accessories. Year(s) : 2015 Location : MIDDLE EAST
Price : On request
More detailsThe Machine is equiped with 290x94 mm adapter, 56 spindles. In the price it is included load on Truck or in C Location : EUROPE (Central and Eastern)
Price : On request
More details. In the price it is included loading on Truck or in Container Location : EUROPE (Central and Eastern)
Price : On request
More details1 x 1997 ICBT embroidery thread making reel polyester yarn twisting 1 x Proses brand 600 kg yarn fixing boile Year(s) : 1997 Location : MIDDLE EAST
Price : On request
More details16 x 192-eye Rifa bucket cotton - viscose - polyester yarn twisting machine 8 x 6 inches, 8 x 4 inches 4 x 60- Year(s) : 2018, 2019, 2020 Location : MIDDLE EAST
Price : On request
More details01 Volkmann VTS05 C TFO, year 1991 104 spindles Alimentation 10” Exit cone 10” pneumatic threading Blower 380 Year(s) : 1991 Location : EUROPE (Western and Northern)
Price : On request
More detailsTwisting yarn into 2 or 3 threads. ring diameter 140 mm and there are 80 spindles Machine was running, in goo Year(s) : 1990 Location : EUROPE (Central and Eastern)
Price : On request
More details- n.18 spindles - ring diameter 200 mm - tube height 600 mm - spindle control transmission by tangential belt Year(s) : 1997 Location : EUROPE (Western and Northern)
Price : On request
More detailsYou can find used Twisting / Two For One (TFO) on Wotol
FAQ - Questions and answers from members
Q: I am interested in a ICBT DTAR 360 and I want to use 3 yarn in TFO to twist in ring twister, possible?
A: This machine is working in same time both TFO and ring Twister together , this machine designed to use each from 2 yarns up to 6 yarns for 1 spindle ring twister together.
Q: Please explain the process of a Barmag DD2000 GT Two for one twister
A :DD2000GT is a double twist twisting machine: two thread twists are generated just with one spindle turn. The twisted material is wound onto a cardboard mandrel using a winding system controlled by the bobbin tension and generating precision crossed bobbins. This model of twisting machine is fully parameterizable: twist direction, number of twists, collection speed, cross ratio, etc.
The machine has a modular structure in sections, with four workstations on each side. Each of the main components (spindle, feeder, winder, etc.) are equipped with their own converters.
The control of each one of the workstations is carried out in a decentralized way through a drive in the workstation. The necessary data, such as spindle revolutions, turns per meter, etc., is centrally registered from the unit drive located in the general distribution board. This data will be the nominal value, for the control of each workstation.
The necessary input data for operation can be collected in formulas that can be saved with a specific number and retrieved at any time. Such data is protected against unauthorized changes.
In this case we have two twisting lines for the generation of 250 mm wide bobbins and a weight of approximately 5 kg.
Q: I have seen a RPR GC120N two for one twister 90 positons. It it suitable bro PES, PP and PR 40 dtex to 200 dtex? How many kg per month of yarn can they produce?
A : Yes these RPR GC120N two for one twister can twist PES, PP and PR.
On these machines we are producing from 33 dtex to 280 dtex at a range of 60 to 2500 twists.
For production it depends on the count of yarn and the numebr of twists. For example we for 100 dtex, 600 twists we were producing more than 10 kg per position per monty (1 ton per machine of 90 position). In case of 280 dtex ith 300 twist we were producing more than 20 kg per position per monty.
Q: I am intersted in a used Memmingen SRZ II 300/250 Ring twister and I need toknow if the main motor have an inverter command.
A : This Memmingen SRZ II 300/250 Ring twister was lelivered in 1990. It has two motors, for each machine side one motor which means each side works independently. In 1990 the machine was supplied without inverter but you can install one if you want.
Q: We are looking for some used twisting machines for fine titers in the range 470 + 550 dtex polyester and polyamide at low budget. What can you recommend?
A: You can produce with used Barmag DD13 or DD23 that can setup current thread title 500 dtex up to 3300 dtex
Q: What is the benefit of a Savio TFO duo pot? I would like to know what is production of 8 spindles on 8/2 ne cotton. This twister put a cone over cone. On top Do not need doublig?
A: Production of Ne 8/2 (Nm13,6/2) with 150 twist per meter will be 96-100 kg/24h on 8 spindles. It is calculated with spindle speed of 8500twist/min, but machine can work with speed of 11000twist/mim and capacity is much greater then. Machine can work as duo pot (one on other cone) with no need of doubling yarn. Machine can work with doubled yarn as well.
Q: Re your used Lezzeni BRD Assembly twister 1995, can I have details of spindle speed and capstan speed?
A: This used Lezzeni BRD is very special. It produces fishnet yarn processin at processing 4.500 rpm. It is gear drive.
Q: What are the dimensions of a used T2T R99 TWISTING MACHINE SIMA from 1989 and please explain more in details what it can produce?
A: The Sima T2T R99 suitable for producing twisted yarn from 10000 to 100000 deniers in natural or synthetic fiber, with spindle - multiple type for producing tubular tubes.
The spool dimension is 8/9 kg on a tube of 300 mm. Weight of the machine 2100 kg. Dimensions: cm 230x110x120
Q: Can I use the take up package with a used RPR TFO two for one twister model GC96DF 120 postions, with heater
A: If you need to put bobins on the take up package, you will need a RPR-GC72 Two for one twister.
Q: Please give me more detaisl about your Yarn twister Custom made with 8 Savio spindles
A: It was made locally. Only spindles are from Savio.
Number of twist lower than 400 is possible of course as well higher number of twists per meter. It can be set with frequency regulator for spindle speed (8 spindles = 8 motors), and winding can be set by gears.
Machine is very economical in electric consumption because it rans as much motors as you use spindles. For example, if you use one spindle at the moment, only one small motor will work to drive the spindle.
Compact yarn twisting machine. It have 8 Savio TFO spindles. Can work as duo pot. Very rare machine. Ideal for small and family knitting and waving productions. Machine can process yarn of different count and type. Unique, hand made. It is in production right now. It have waxing device to.
Production of Ne 8/2 (Nm13,6/2) with 150 twist per meter will be 96-100 kg/24h on 8 spindles. It is calculated with spindle speed of 8500twist/min, but machine can work with speed of 11000twist/mim and capacity is much greater then. Machine can work as duo pot (one on other cone) with no need of doubling yarn. Machine can work with doubled yarn as well.
Dimensions of the machine are: 3.3m x 1m x 1.8m.
Q: We are interetsed in your used Muratec 368 Two For One Twister 1995. What is the power supply of the machines,what type of tube that fits into the basket (we feed with 8-inch cylindrical tube)?
A: The Power supply of our Murata 368 is set up for 380 V., 50/60 Hz. (it has an inverter, so frequency is no problem). Feed is by cylindrical tubes, 42 mm inside diameter, 20 cm. in length. Pot diameter is 20 cm. If we still have some tubes, we will include them. It requires compressed air for the yarn to be threaded down the twisting hole. Take up is 5 56’ cones, 6 inches length. It has waxing device.
Q: What are the dimensions of the element of a used Oerlikon, Volkmann VTS05-0-C Carpet Cabler from 2007 with 104 spindles?
A: Volkmann VTS05-0-C with 104 spindles is composed of 13 elements of cm 200 x 150 x 270 (h) Some parts can be dismantled to reduce heigh for transport + 1 element cm 200x145x200
Q: What is the difference between a cabling machine and a twisting machine?
A: Two for one twisting and yarn cabling are both mechanical impovement of the yarn characteristics. Once cabling done there will be a perfect formation of the hair in case of carpet weaving? In dircet cabling two yarns are twisted one around the other in one operation. This will inmrove the alignement and the cohesion of the fibers.
Q: Regarding your used Lezzeni TBR / LA yarn twisting 1990 how many bobbins and cops are available exactly? How many spindles are in working condition and how many spindles are missing ? How many pulleys are available and in what sizes ? Can you also explain the technical terms?A:
A: Bobbins are the reels on which yarn is loaded and put on top row of the used Lezzeni TBR / LA yarn twisting . If the machine has 80 spindles, that means 240 bobbins must be loaded on top row. And another 240 must be available for loading and unloading at the same time. That means minimum 480 bobbins must be present. Cops are the reels that are on spindles and twisted twine is loaded on them. Same logic as above minimum 160 cops must be present. Pulleys and the sprocket wheels of different diameters are needed for adjusting TPM values.
