Acer AGS-1020AHD

ACER AGS-1020AHD
2010

Max. surface ground 10" x 20"
Distance spindle center to table 19.5"
Variable table speed 16–80 FPM
Max. table travel 20.5"
Automatic crossfeed increment 0"–1"
Max. crossfeed travel 11"
Downfeed handwheel per graduation 0.0005"
Downfeed handwheel per revolution 0.1"
Crossfeed handwheel per graduation 0.001"
Crossfeed handwheel per revolution 0.2"
Auto incremental downfeed 0.001"–0.0001"
Spindle motor 2 HP
Grinding wheel 8" x 1/2" x 1-1/4"
Approx. weight 2,970 lbs

Automatic incremental downfeed
Power rapid wheelhead positioning
Hydraulic longitudinal feed
Power crossfeed
Turcite-B longitudinal ways
8" x 18" electromagnetic chuck
Variable hold neutrofier control
Coolant system with dust collector
Over-the-wheel dresser
Newall 2-axis digital readout
Meehanite casting
Auto lube system
External hydraulic system
2 HP hydraulic pump motor
3/60/230V wiring
