Agfa Avalon N8-60

Thermal Plate Recorder
System Overview & Status:
The system is in good condition, currently in production, and can be inspected and tested at any time.
Total plate winding cycles: 649,254.
The package includes the CTP recorder, single-cassette autoloader,
on-line plate processor, plate stacker, controlling PC, and workflow software.

Technical Specifications:
Model: AGFA Avalon N8-60 S / XT (OEM Screen PlateRite 8900)
Imaging System: Grating Light Valve (GLV) technology
Laser Technology: 830 nm Thermal Laser Diodes (512 beams)
Recording System: External drum
Resolution: 2400 dpi (4000 dpi factory option)
Maximum Plate Size: 1165 x 950 mm (45.9 x 37.4 inches)
Minimum Plate Size: 304 x 305 mm (11.9 x 12.0 inches)
Plate Thickness: 0.15 to 0.3 mm (6 to 12 mil), with options for 0.4 mm support
Maximum Imaging Area: 1165 x 938 mm (45.9 x 36.9 inches) with 6/6 mm grip

Line Components & Automation:
Autoloader: Single Cassette Autoloader Agfa SA-L8900 (Year of manufacture: 2010).
Features automatic slip-sheet removal for unattended operation;
Plate Processor: Agfa Elantrix 125HX / Glunz & Jensen QUARTZ III 125 (Year of manufacture: 2011).
Heavy-duty thermal plate processor connected on-line;
Plate Stacker: Advand PST480;

Software & Control:
RIP / Workflow: Agfa Apogee version 13.0.0 (Release date: 06/06/2023);
Control Hardware: Dedicated workstation (Management PC) and all necessary software driving licenses are included in the package.
Still in production.
Very good working condition.
