Agietron EMS 3.30 Die sinking machine
Ref :
2398625-3-GO
Condition :
Used
Manufacturer :
Agietron
Model :
EMS 3.30
Short Description :
Die sinking machine
Year(s) :
1979
Quantity :
1
Location :
Seller or machines location:
EUROPE (Western and Northern)
EUROPE (Western and Northern)
AGIETRON EMS 3.30
Year of construction 1979
Table size: 630 x 500 mm
gr. workpiece height: 340 mm
Adjustment = X: 420 mm
Adjustment = Y: 320 mm
gr. workpiece weight: 8000 N
Reading option: 0.01 mm
gr. distance of table quill: 700 mm
Work container: 945 x 650 x 465 mm
Feed travel = Z: 400 mm
Rapid traverse and servo speed: 600 mm / min
Outreach: 500 mm
Agiepuls generator: Type 60 L / DDL
Rated current: 60 A
Pulse voltage: 100/150/270 V.
Dielectric aggregate: Type DA 220
Capacity: 450 mm
Weight: 1540 kg
very little used, in very good condition
