AK Bend AHK Y 300 x 3100

Machine type: Plate Bending Machine - 3 Rolls
Control: Conventional
Sheet width: 3100 mm
Plate thickness: 13.0 mm (ST)
Pre-bending: 10.0 mm (ST)
Upper roll diameter: 300 mm
Side roll diameter: 270 mm
Bending speed: 4.5 m/min
Voltage: 415 V
Total power requirement: 11.0 kW
Weight: 8200 kg
Machine dimensions (L x W x H): 5090 x 1620 x 1630 mm


Robust electro-hydraulic 3-roll bending machine
Induction-hardened rolls
Stable welded construction
SIEMENS ELGO digital position indicator
Position indicator for two side rolls
Freely movable control panel
Curved side roll feed
Electro-hydraulic conical bending device
Electro-hydraulic safety chuck
Pressure gauge for rolls
Operating instructions (PDF)
Two AK BEND side supports (lateral sheet metal support system)
Bending rolls with profile roll extension
Various profile rolls included
